LEXMOTO Diablo EFI 125 2020
Overview
Specs
Finance
Price Promise
LEXMOTO DIABLO 125cc
Premium Sports Scooter, Designed in Italy - supplied by WhateverWheels.

APPLY FOR FINANCE
WhateverWheels are the North West's Official Lexmoto dealer located in Blackburn, Lancashire and are happy to introduce the Lexmoto Diablo 125cc Twist & Go Scooter!
The Diablo has everything of a well styled sports scooter which is built to specifications that far surpass its price tag. Modern Italian style looks, and a racy 6.5Kw EFI overhead cam power plant which is the most powerful of the all the Lexmoto scooter range. The front and rear combined disc brakes and jolt soaking suspension allow nimble handling around the twists. An easy read digital display combines flair and practicality and the striking LED headlight unit warns others of your impending arrival.

EURO 4
This bike complies with the Euro-4 emissions regulations as certified by EU member state.
COMBINED BRAKING
Combined braking distributes the braking between both wheels, reducing braking distance and the tendency to skid.
DIGITAL DISPLAY
This bikes comes with an easy to view digital display, which gives you all the information you need whilst riding.
POWERFUL MOTOR
Be first off the line with a motor that delivers premium performance in the range.
TWIST'N'GO
A Great option for new riders this automatic option simply requires a throttle to be used without the need for clutch and gear use.
LED INDICATORS
LED lights are brighter and last far longer than traditional light bulbs.
Model Name: Lexmoto Diablo 125 EFI
Model Code: LJ125T-8M-E4
Fuel Capacity: 6 Litres
PERFORMANCE
Max KMH: 90 kph
Max Power: (8.7 hp) 6.5KW @ 7500
ENGINE
Engine Brand: 1P52QMI
Engine Type: Single Cylinder
Engine Stroke: 4 Stroke
Engine Cooling: Air Cooled
Displacement: 125 cc
Bore x Stroke: 52.4 x 57.8
Gear Type: Twist and Go
Drive Type: Belt
Start Type: Electric Start Only
Ignition Type: EFI
Battery Voltage: 12v
WHEELS
Front Brake: Hydraulic Disc
Rear Brake: Hydraulic Disc
Front Tyre: 120/60-13
Rear Tyre: 130/60-13
Tyre Brand: CST
Tyre Model: Tubeless
Front Suspension: Telescopic Forks
Rear Suspension: Mono Shock Absorber
DIMENSIONS
Length: 1840 mm
Width: 690 mm
Height: 1150 mm
Seat Height: 790 mm
Wheelbase: 1305 mm
Mass in Running Order: 114 kg
Maximum Laden Mass: 264 kg
LEXMOTO DIABLO 125 TECHNICAL DATA
Minimum Licence Required: CBT or A1 (UK Entitlement)
CAP/ABI Code: LXDO013FISC A BUB
Odometer Reading: Dual
Speedo Type: Digital
Parking options: Centre and Side Stand
Power Output
Max. Power: 6.5 @ 7500 kW @ RPM
Engine Setting
Capacity: 125 cc
Valves per cylinder: 2
Engine Type: LJ1P52QMI
Cylinders: Single
Cooling: Air Cooled
Bore x Stroke: 52.4mmX57.8mm
Compression Ratio: 10.5:1
Stroke: 4 Stroke
Timing and Ignition
Spark Plug: NGKÃ??¯¼?CR7HSA
Ignition: EFI
Fuel System
Carburettor Type: EFI Delphi
EFI System: Delphi
EFI Plug Location: Behind Rear Right Panel
Valve Clearances
Exhaust Valve (Metric): 0.07-0.12 mm
Inlet Valve (Metric): 0.07-0.12 mm
Electrical
FusE: 15 A
Battery: 12V7Ah
Battery Location: Under Footwell Panel
Drive
Drive Belt: 818 19.7 28
Handling and Suspension
Fork Oil Volume: 115 ml per leg
Fork Oil Grade: 10W
Tyre Pressures
Front: 29 psi
Rear: 33 psi
Fluids
Engine Oil Grade: SAE 10W-40
Engine Oil Volume: 850 ml
Gearbox Oil Grade: GX 80W-90 API GL-4
Gearbox Oil Volume: 150 ml
- WHAT IS INCLUDED?
- WHY BUY FROM US?
- WARRANTY
- WHAT IS OTR CHARGE?
- OFFERS
- INSURANCE
- IMPORTANT
Model Year | 2020 |
---|---|
Options | Black / Grey ORDER NOW - Fast Delivery Red Unavailable Black / Orange Unavailable |
MAX SPEED | 90kph |
MAX POWER | 6.5Kw @ 7500rpm |
MAX LOAD | 264kg |
ENGINE SIZE | 125cc |
ENGINE TYPE | Single Cylinder 4 Stroke Air Cooled |
ENGINE BRAND | 1P52QMI |
BORE X STROKE | 52.4 x 57.8mm |
TRANSMISSION TYPE | Automatic |
GEAR TYPE | Twist and Go |
CLUTCH TYPE | CVT Auto |
DRIVE TYPE | Belt Driven |
START SYSTEM | Electric Start Only |
IGNITION TYPE | ECU |
BATTERY VOLTAGE | 12v |
FRONT TYRE | 120/60-13 |
REAR TYRE | 130/60-13 |
TYRE MODEL | CST |
FRONT SUSPENSION | Telescopic Forks |
REAR SUSPENSION | Twin Shock Absorber |
FRONT BRAKE | Hydraulic Disc Brake |
REAR BRAKE | Hydraulic Disc Brake (Combined Braking System) |
SEAT HEIGHT | 810mm |
WHEELBASE | 1305mm |
OVERALL LENGTH | 1840mm |
OVERALL WIDTH | 690mm |
OVERALL HEIGHT | 1150mm |
Unladen Weight | 114Kg |
